Mondraker Dusty X

Mondraker Dusty X
  • Color: Bunker Grey
$7,499.00
Color: Bunker Grey
Size: Medium
Wheel Size: 29-inch
Please select options Unavailable

Details

The DUSTY X is akin to the DUSTY SX, perfect for an urban setting, your daily commute and longer weekend rides to blow the cobwebs away; yet at the same time it’s more versatile than the SX, coming into its own on those winter days or summer evenings when the twilight could impede on your safety. It comes with a flat 640mm-wide handlebar, a bar-mounted 150-lumen headlight, and a Supernova seatpost with a built-in LED rear light. Given the position of the headlight on the handlebar, we’ve integrated the Pulsar One display into the stem cap.

Sizes:
Frame sizeSmallMediumLargeX-Large
Seattube length 440 mm 460 mm 500 mm 530 mm
Toptube length 550 mm 570 mm 595 mm 620 mm
Bottom bracket drop 70 mm 70 mm 70 mm 70 mm
Bottom bracket height 286 mm 286 mm 286 mm 286 mm
Chainstay length 425 mm 425 mm 425 mm 425 mm
Seat tube angle 74º 74º 74º 74º
Effective seattube angle 74º 74º 74º 74º
Headtube angle 70º 70º 70º 70º
Fork Offset 45 mm 45 mm 45 mm 45 mm
Wheelbase 1034 mm 1056 mm 1082 mm 1110 mm
Headtube length 125 mm 150 mm 175 mm 210 mm
Reach 393 m 405 mm 424 mm 440mm
Stack 548 mm 576 mm 595 mm 628 mm
Stem Length 70 mm 70 mm 80 mm 90 mm
Fork Height 420 mm 420 mm 420 mm 420 mm

Specs

Frame Dusty Stealth Air Carbon, pressfit 386 EVO bottom bracket, tapered head tube, HHG internal cable routing, integrated internal non-removable battery, 12x142mm rear axle, 1X or 2X drivetrain design, Flatmount brake compatible, integrated dropout speed sensor.
Fork Steatlh Air Carbon tapered steerer tube, HHG, fllat mount integrated fork
Rims MDK-XG1, 25mm internal width, tubeless ready, 28 spokes
Hubs Front: Novatec D041, Boost 12x100mm, sealed bearings, IS 6 bolts
Rear: Mahle X20 Drive Unit, HG freehub
Spokes CN round stainless steel
Tires Maxxis Re-fuse 700x40, tubeless ready, dual compound, MaxxShield EXO protection, 60 TPI, folding bead
Bottom Bracket Mahle DUB pressfit, sealed bearings, w/ torque sensor
Crankset SRAM Apex 1 Wide, size S: 170mm, size M: 172,5mm, size L: 172,5mm, size XL: 175mm.
Chainrings SRAM X-Sync Eagle 40T direct mount, alloy, narrow-wide,
Shifters SRAM Trigger GX Eagle, 12s, X-Actuation 1:1
Rear Derailleur SRAM Apex XPLR 12s
Cassette/Freewheel SRAM PG-1231 11-44, 12s
Chain SRAM Apex, 12s, Powerlock
Brakes SRAM Level Silver 2P Stealth, 2 piece flatmount caliper, Centerline 160mm IS 6 bolts one-piece rotor, steel-backed organic pad
Brake Levers SRAM Level Silver, tools-free reach adjust, lever pivot bearings
Handlebars MDK Urban 1.0 double butted 6061 alloy, rise: 0mm, width: 640mm, 9º backsweep, 0º upsweep, 31.8mm barbore
Tape/Grips Lizard Skins DSP 30.3
Stem OnOff gravel 6061 T6 Alloy, 31.8mm barbore, rise: +/-7º, length: sizes S/M: 70mm, size L: 80mm, XL: 90mm
Headset OnOff gravel tapered for 1-1/8” to 1-1/2” head tube, ACB sealed bearings, top 41x30.2x7x45ºx45º, bottom 51.9x40x8x45ºx45º
Seatpost Seatpost with integrated Supernova led rear light, diameter 27.2mm, length 400mm
Saddle Selle Royal Prestige 139mm
Pedals Sold Separately
Motor Mahle X20 Drive Unit
Battery Mahle X20 IX350Wh
Controller/Display Pulsar One Wireless/ DUO remote

* Subject to change without notice.

Part Numbers

Option UPC MPN Store SKU
Bunker Grey / Medium / 29-inch 08435392890533 MO-010-25US404 DUS17395555M
